Designed to win, the new KEO BLADE CARBON improves the experience associated with the use of blade technology in a clipless pedal. This new version is the result of experience gained during years of development in the heart of our manufacturing facility and to continual improvements made thanks to daily input from the greatest of champions.

Lightweight, aerodynamic, powerful, the new KEO BLADE CARBON has all the assets to allow you to improve and optimize your performance until victory is yours. It is for these reasons that KEO BLADE CARBON is the unanimous choice of many champions who have made it a weapon of choice in the conquest of their greatest achievements.
Its new design completely integrates the blade for unrivaled aerodynamics. Equipped with a carbon body and blade, the Blade Carbon is available in a Ti version (titanium spindle) that weighs a mere 95g per pedal, or in a CrMo version (chromoly spindle) for a weight of 110g per pedal. It is available in three tension release levels: 12,16 and 20.

• USE
• Race
• BODY
• Carbon
• SPINDLE
• Chromoly Steel +
• THREADING
• 9/16 X 20 mm
• BEARINGS
• 1 roller bearing, 1 needle bearing
• STACK HEIGHT
• 14.8 mm
• DISTANCE PEDAL SPINDLE / CRANKARM
• 53 mm
• PLATFORM WIDTH
• 67 mm
• PLATFORM SURFACE AREA
• 700 mm
• TENSION
• Pedals come installed with 12 carbon blades + additional 16 carbon blades
• (20 carbon blades sold separately)
• CLEATS
• Ko Cleats-Gray
• FLOAT
• 0 , 4.5 or 9 according to the cleat color (Black, Grey, Red)
• PEDAL WEIGHT
• 110 gr (288 gr per pair with cleats and screws)
• COLORS
• Black
