Aerodynamics, efficient acceleration and improved handling by UST Tubeless: nothing is missing from this road wheel specially designed for rim brakes! On the program, Road Tubeless technology and ever more lightness
- SPECIFICATIONS
- Compatibility
- Freewheel: Shimano Micro Spline
- Rear axle: 12mm thru axle, convertible to Quick Release with optional adapters
- Freewheel: Shimano/Sram or XD
- Compatible Adapters and freewheel bodies
- ID360 Shimano Micro Spline alloy freewheel body (LV3990100)
- Boost : 12x148 rear axle adapters (LV2510700 - Delivered with the wheel)
- ID360 XD freewheel body (LV3740100)
- ID360 Shimano alloy freewheel body (LV3780100)
- ID360 Shimano steel freewheel body (LV3790100)
- Weight
- Pair 650b/27,5" without tyre: 1930 grams
- Front 650b/27,5" without tyre: 860 grams
- Rear 650b/27,5" without tyre: 1070 grams
- Pair 29" without tyre: 1940 grams
- Front 29" without tyre: 915 grams
- Rear 29" without tyre: 1025 grams
- Hubs
- Front bearings : adjustable sealed cartridge bearings (QRM+), Rear bearings : auto adjust sealed cartridge bearings (QRM Auto)
- Freewheel: Instant Drive 360
- Front and rear bodies: aluminum
- Intended Use
- Recommended tyre sizes: 46mm to 64mm (1.8" to 2.5")
- For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
- ASTM CATEGORY 4 : ENDURO AND TRAIL RIDING
- Rims
- ETRTO size 29": 622x28TSS
- Internal width: 28 mm
- ETRTO size 27.5": 584x28TSS
- Hookless profile
- Weight reduction: ISM 4D
- Valve hole diameter: 6.5 mm
- Tyre: UST Tubeless and tubetype
- Drilling: Fore
- Material: Maxtal
- Spokes
- Shape: straight pull, flat
- Lacing: front crossed 2, rear Isopulse
- Nipples: Fore integrated aluminum
- Count: 24 front and rear
- Material: Zicral
- Versions
- Freewheel: Shimano/Sram or XD
- Hub width : Boost (front 110, rear 148) or Non-Boost (front 100, rear 135/142)
- Disc standard : 6 Bolts only
- Color: Black only
- DELIVERED WITH
- Sram XD (on the wheel) and Shimano HG freewheel bodies
- Replacement spokes (2 with the front wheel and 4 with the rear)
- Multifonction adjustment wrench
- Specific disc bolts
- UST valve and accessories
- User guide
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Ultra-responsive ride quality.
- 28mm wide (internal) rims proven fastest through extensive testing with top pro enduro racers.
- ISM 4D construction, Isopulse lacing and 24 Zicral spokes deliver maximum acceleration in a lightweight package.
- Confident handling and durability you can count on.
- ISM 4D rim technology minimizes weight without sacrificing strength.
- Maxtal alloy rims and Zicral spokes for added strength and durability.
- UST Tubeless for added traction and control.
- User-friendly tubeless technology for better traction and control with reduced risk of punctures.
- Wheelset ships with UST valves.
|
|
|
|
|
|
|
|
|
