Confident handling
Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.
- SizesS, M, M/L, L, XL
- ColoursGloss Cordovan/Dried Herb
- FrameALUXX-grade aluminium, 12x142mm thru-axle, disc, flip chip dropout
- ForkAdvanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
- ShockN/A
- HandlebarGiant Contact XR D-Fuse, 31.8mm
- Gripscork tape with gel
- StemGiant Contact, 8-degree
- SeatpostGiant D-Fuse, alloy, 14mm offset
- SaddleGiant Approach
- PedalsPEDALS NOT SUPPLIED
- ShiftersShimano GRX RX-400, 2x10
- Front DerailleurShimano Tiagra
- Rear DerailleurShimano GRX RX-400
- BrakesShimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
- Brake LeversShimano GRX RX-400 hydraulic
- CassetteShimano HG500, 11x34
- ChainKMC X10 with Missing Link
- CranksetFSA Omega Adventure, 32/48
- Bottom BracketFSA Mega EXO
- RimsGiant S-X2 Disc wheelset, alloy, 25mm inner rim width
- HubsGiant alloy, 12mm thru-axle
- SpokesStainless steel
- TyresGiant CrossCut AT 2, 700x38c, tubeless
- ExtrasFactory tubeless set up, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position
- Max Chainring SizeSRAM Wide 2x 43-30, 1x 46T. SRAM Road 2x 52-39, 1x 52T. Shimano Road 2x 52-36. GRX 2x 48-31, 1x 42T
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Tuned compliance
- Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.
- Adaptable to the terrain
- A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.
|
|
|
|
|
|
|
|
|
