With an impressive stiffness-to-weight ratio and updated aero tube shaping, this frameset is engineered to give road racers and riders superior climbing capabilities, aerodynamic efficiency and sprint stiffness for race-winning performance.
- SizesXS, S, M, M/L, L, XL
- ColoursPurple Haze/Ultra Violet, Dreamy Blue
- FrameAdvanced-grade Composite, 12x142mm thru-axle, disc
- ForkAdvanced-grade Composite, full-composite OverDrive steerer, 12x100mm thru-axle, disc
- ShockN/A
- HandlebarGiant Contact XS:38cm, S:38cm, M:40cm, M/L:40cm, L:42cm, XL:42cm
- StemGiant Contact AeroLight XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
- SeatpostGiant Variant, composite, -5/+15mm offset
- SaddleGiant Approach
- ShiftersShimano 105 Di2
- Front DerailleurShimano 105 Di2 FD-7150
- Rear DerailleurShimano 105 Di2 RD-7150
- BrakesShimano 105 Di2 hydraulic, Shimano SM-RT64 rotors [F]160mm, [R]140mm
- Brake LeversShimano 105 Di2
- CassetteShimano 105, 12-speed, 11x34
- ChainKMC X12L-1
- CranksetShimano 105, 36/52 XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm
- Bottom BracketShimano, press fit
- RimsGiant P-R1 Disc wheelset, alloy, [F]30mm, [R]30mm
- HubsGiant alloy, 12mm thru-axle
- Spokesstainless
- TyresGiant Gavia Course 0, tubeless, 700x28c (28mm), folding
- Extrastubeless prepared, 33mm max tire size
- Max Tire Clearance33mm
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
- Class-leading efficiency
- With an impressive stiffness-to-weight ratio and updated aero tube shaping, this frameset is engineered to give road racers and riders superior climbing capabilities, aerodynamic efficiency and sprint stiffness for race-winning performance.
- Advanced aerodynamics
- This is where the TCRs most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.
- Total control
- Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tires up to 32mm.
|
|
|
|
|
|
|
|
|
